OLT ZTE C300/320 di ONT Mode Port: Vlan_Translate, QinQ, Trunk & Access
Contoh Config
1. Vlan Translate QinQ To Access:
OLT-ZTE-C320#show run interface gpon-onu_1/4/1:21
Building configuration...
!
interface gpon-onu_1/4/1:21
name RSO0766
description Customer_Vlan-Translate
tcont 6 name Internet_Vlan-Translate profile UP-100M
gemport 6 name Internet_Vlan-Translate unicast tcont 6 dir both
switchport mode hybrid vport 6
service-port 6 vport 6 user-vlan 1490 vlan 1490 svlan 1479
!
end
OLT-ZTE-C320#show onu running config gpon-onu_1/4/1:21
pon-onu-mng gpon-onu_1/4/1:21
service Internet_Vlan-Translate gemport 6 vlan 1490
vlan port eth_0/4 mode tag vlan 1490
dhcp-ip ethuni eth_0/4 from-internet
!
2. Vlan QinQ Access:
OLT-ZTE-C320#show run interface gpon-onu_1/2/5:22
Building configuration...
!
interface gpon-onu_1/2/5:22
name Internet-QinQ-Access
description QinQ-Access
tcont 1 name Acsata profile UP-200M
tcont 1 gap mode2
gemport 1 name Internet unicast tcont 1 dir both
gemport 1 traffic-limit upstream DOWN-200M downstream DOWN-200M
switchport mode hybrid vport 1
service-port 1 vport 1 user-vlan 1269 vlan 1269
!
end
OLT-ZTE-C320#show onu running config gpon-onu_1/2/5:22
pon-onu-mng gpon-onu_1/2/5:22
service Internet gemport 1 vlan 1269
vlan port eth_0/4 mode tag vlan 1269
!
3. Vlan Trunk:
OLT-ZTE-C320#show run interface gpon-onu_1/3/9:22
Building configuration...
!
interface gpon-onu_1/3/9:22
name Customer-Trunk
description Customer-Trunk, Red Sapphire 3 No 38, 081908666324, 02/06/2020, FM
tcont 3 name Internet-Trunk profile UP-100M
tcont 4 name TV_Trunk profile UP-100M
tcont 5 name OAM_Trunk profile UP-10M
gemport 3 name Internet-Trunk unicast tcont 3 dir both
gemport 3 traffic-limit upstream DOWN-100M downstream DOWN-100M
gemport 4 name TV_Trunk unicast tcont 4 dir both
gemport 5 name OAM_Trunk unicast tcont 5 dir both
switchport mode hybrid vport 3
switchport mode hybrid vport 4
switchport mode hybrid vport 5
service-port 3 vport 3 user-vlan 1000 vlan 1000
service-port 4 vport 4 user-vlan 2000 vlan 2000
service-port 5 vport 5 user-vlan 32 vlan 32
!
end
OLT-ZTE-C320#show onu running config gpon-onu_1/3/9:22
pon-onu-mng gpon-onu_1/3/9:22
service Internet-Trunk gemport 3 vlan 1000
service TV_Trunk gemport 4 vlan 2000
service OAM_Trunk gemport 5 vlan 32
vlan port eth_0/3 mode trunk
vlan port eth_0/3 vlan 32,1000,2000
!
4. Config WIFI di ONT:
OLT-ZTE-C320#show run interface gpon-onu_1/1/1:3
Building configuration...
!
interface gpon-onu_1/1/1:3
name SMP0001
description David Gatot Subroto
tcont 1 name FTTH-Simprug profile UP-20M
tcont 2 name Smartmeter profile UP-1M
gemport 1 name FTTH-Simprug unicast tcont 1 dir both
gemport 1 traffic-limit upstream DOWN-20M downstream DOWN-20M
gemport 2 name Smartmeter unicast tcont 2 dir both
gemport 2 traffic-limit upstream DOWN-1M downstream DOWN-1M
switchport mode hybrid vport 1
switchport mode hybrid vport 2
service-port 1 vport 1 user-vlan 673 vlan 673
service-port 2 vport 2 user-vlan 676 vlan 676
!
end
OLT-ZTE-C320#show onu running config gpon-onu_1/1/1:3
pon-onu-mng gpon-onu_1/1/1:3
service FTTH-Simprug gemport 1 vlan 673
service Smartmeter gemport 2 vlan 676
vlan port eth_0/1 mode tag vlan 673
vlan port eth_0/2 mode tag vlan 676
vlan port wifi_0/1 mode tag vlan 673
!
